AIDA PTZ-X20-IP Broadcast FHD IP/SRT/SDI/HDMI/USB3 PoE PTZ Camera 20X Zoom

AID-PTZ-X20-IP
$2,100.26
PRICE EXCLUDES GST. THIS WILL BE ADDED AT CHECKOUT.
FAST DELIVERY. FREE SHIPPING & returns.
PRE-ORDER (SHIPS IN 3-4 WEEKS)

unavailable

PRE-ORDER (SHIPS IN 3-4 WEEKS)

The AIDA PTZ-X20-IP delivers broadcast-grade performance in a compact, network-enabled PTZ camera. With 20X optical zoom and Full HD 1080p resolution, it excels in live streaming, conferences, and professional productions. Multiple connectivity options—IP, SRT, SDI, HDMI, and USB3—integrate seamlessly into any workflow. PoE power simplifies installation by eliminating the need for separate power cables. Engineered for reliability in demanding environments, this camera combines versatility with professional-grade image quality, making it ideal for studios, houses of worship, education, and corporate installations.

Product overview

Key product features

- Full HD Progressive Scan sensor captures sharp and vivid colour.
- Advanced digital image processor provides vivid and detailed images with full access feature sets.
- Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur.
- 3G/HD-SDI, HDMI, RJ-45, USB 3.0, and USB 2.0 for versatility and seamless video performance.
- Power Optical Zoom capability up to 20X.
- Compatible with other industry-leading products, conforming to SMPTE 424M/292M standard.
- Auto White Balance and shutter speed provide optimised performance in a variety of situations.
- Built-in OSD controls for customizable image settings.
- Versatile and compact.

Data & specifications sheet

Model: AIDA PTZ-X20-IP
Camera Type: Full HD IP Broadcast & Conference PTZ Camera
Image Sensor:1/2.5" Progressive CMOS
Effective Resolution: 1920 × 1080
Video Formats: 1080p, 1080i, 720p
Maximum Frame Rate: 1080p60
Optical Zoom: 20x Optical Zoom
Lens Aperture: F1.5 to F3.0
Field of View: 72.5°
Video Outputs: 3G-SDI, HD-SDI, HDMI, USB 3.0, USB 2.0, RJ45 IP Streaming
Streaming Protocols: TCP/IP, RTSP, RTMP
Colour Space: 4:2:2 (YCbCr), 10-bit
Minimum Illumination: 0.1 Lux
White Balance Modes: Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor
Focus Modes: Auto & Manual
Shutter Speed: 1 to 1/10,000 sec
Pan Range: 340°
Tilt Range: +90° to -30°
Pan Speed: Up to 120°/sec
Tilt Speed: Up to 80°/sec
Preset Positions: 128 Presets
Control Protocol: VISCA
Control Interfaces: RS-232C In/Out, RJ45 Ethernet
Power Options: 12V DC or PoE+ (IEEE 802.3at)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Dimensions: 155 × 160 × 170 mm
Weight: 1.35 kg
Standards Compliance: SMPTE 292M, SMPTE 424M

FAQs

1. What is the AIDA PTZ-X20-IP used for?

The PTZ-X20-IP is a professional Full HD PTZ camera designed for live streaming, broadcast production, houses of worship, education, corporate AV, conference rooms, and hybrid events that require flexible remote camera control.

2. What zoom capability does the PTZ-X20-IP offer?

The camera features a powerful 20x optical zoom lens, enabling operators to capture both wide shots and detailed close-ups while maintaining image quality.

3. What video outputs are available on the PTZ-X20-IP?

The PTZ-X20-IP supports IP streaming, SRT, 3G-SDI, HDMI, USB 3.0 and USB 2.0 connectivity, making it suitable for a wide range of professional broadcast and AV workflows.

4. Does the PTZ-X20-IP support Power over Ethernet (PoE)?

Yes. PoE support allows power, control, and network connectivity to be delivered over a single Ethernet cable, helping simplify installation and reduce cabling.

5. How does the PTZ-X20-IP perform in different lighting conditions?

The camera uses a Full HD Progressive Scan sensor, advanced image processing, automatic white balance, and noise reduction technology to produce clear, detailed video across varying lighting environments.

6. What makes the PTZ-X20-IP different from other PTZ cameras?

The PTZ-X20-IP combines professional Full HD image quality, 20x optical zoom, multiple video outputs, PoE connectivity, and smooth remote PTZ operation, making it a versatile solution for modern production and AV installations.
